1. Power input: 12V/5A
2. Support system: Win10Win11Linux
3. Working environment temperature: -10 degrees to 50 degrees
4. CPU: Intel Celeron J4125 (4M cache, base frequency 2.0 GHz up to 2.70 GHz 4 cores 4 threads)
5. TDP: 10W
6. Photolithography: 14nm
7. Memory slot: 2xDDR4 260Pin SODIMM, maximum support 24G, installing more than 24G memory will result in failure to enter the system
8. Supported memory frequency (speed): 2400Mhz
9. Sound card: no 3.5mm audio port, 1xintel sound card, HDMI port transmission
10. I/O interface: 2xUSB3.0, 2xUSB2.0, DC input port x1, 4xRJ45, 2x external antenna interface for WiFi module/4G module signal gain, 1xDB 9Pin RS232
11. Video port: 1xHDMI 4K/30Hz
12. Storage ports: 1xMSATA, 1xSATA3.0, for installing 2.5-inch HDD/SSD
13. Expansion slot/mainboard common interface: 1xMPCIE full-height slot for installing WIFI module/3G/4G module, 1×9 Pin USB 2.0 header for extending USB port, 1xSMI card slot for standard SIM card, 1xFP1 row Pins for extending Power sw, Reset, Power LED, HDD LED
14. Installation method: put on the desktop, support VESA hanger, support rail hanger
15. Graphics card model: Intel UHD Graphics 600
Specification:
| Package Weight |
| One Package Weight |
2.00kgs / 4.42lb |
| One Package Size |
31cm * 21cm * 8cm / 12.2inch * 8.27inch * 3.15inch |
| Carton Weight |
41.00kgs / 90.39lb |
| Carton Size |
64cm * 44cm * 42cm / 25.2inch * 17.32inch * 16.54inch |
| Loading Container |
20GP: 225 cartons * 20 pcs = 4500 pcs
40HQ: 523 cartons * 20 pcs = 10460 pcs |
|
